The AXIS Q3819-PVE is a high-resolution panoramic multisensor network camera designed for wide-area surveillance. It combines four image sensors to provide a seamless panoramic view of up to 180° horizontally, helping security teams monitor large outdoor areas with a single camera and a single network connection. Its rugged, weather-resistant and vandal-resistant housing makes it suitable for demanding security installations.
The AXIS Q3819-PVE is designed for continuous monitoring of large spaces where broad situational awareness is important. Its four-sensor architecture combines the images into a panoramic video stream with a maximum resolution of 8192 × 1728 pixels.
The camera incorporates Axis Lightfinder technology for low-light performance and Forensic WDR to help preserve useful image details in scenes with contrasting light and shadow. Remote pan, tilt and roll adjustments allow installers to fine-tune the camera's viewing direction after installation.
For outdoor deployment, the camera features IP66/IP67 weather protection and an IK10 impact-resistant enclosure. It supports Power over Ethernet (PoE), H.264 and H.265 video compression, microSD card storage, and network-attached storage. Axis security features include signed operating system and secure boot.
Specification
Details
Manufacturer
Axis Communications
Model
AXIS Q3819-PVE
Camera type
Panoramic multisensor network camera
Image sensors
Four CMOS sensors
Sensor size
1/2.5 inch
Maximum resolution
8192 × 1728 pixels
Maximum frame rate
30 fps
Horizontal field of view
180°
Vertical field of view
38°
Lens focal length
5.89 mm
Low-light technology
Axis Lightfinder
Wide Dynamic Range
Forensic WDR
Minimum illumination
0.16 lux colour; 0.06 lux black and white
Day/night functionality
Yes
Video compression
H.264, H.265, MJPEG
Bandwidth optimization
Axis Zipstream
Video analytics
AXIS Object Analytics
Network interface
Shielded RJ45, 1000BASE-T
Power supply
IEEE 802.3at Type 2 PoE, Class 4
Typical / maximum power
12 W / 22.5 W
Local storage
microSD, microSDHC, microSDXC
Audio
Audio input and network audio integration
Alarm I/O
Two configurable supervised inputs/digital outputs
Weather protection
IP66 / IP67
Impact resistance
IK10
Additional environmental rating
NEMA 4X
Operating temperature
−40°C to +50°C
Dimensions
Approx. 195 mm diameter × 170 mm height
Weight
Approx. 2.4 kg
Cybersecurity
Signed OS, secure boot, Axis Edge Vault / TPM
Warranty
Five-year warranty, subject to Axis terms
