The GEUTEBRÜCK G-ST 8000+ G3/2U is a professional, rack-mounted video recording server designed for large-scale CCTV surveillance systems. It supports high-throughput video recording, integrated RAID storage, redundant power supplies, and GEUTEBRÜCK video management software.
Its 2U rack-mount chassis accommodates up to eight hot-swappable HDDs, with RAID configurations for video storage. Redundant hot-swappable power supplies help improve hardware availability. The system supports direct recording and playback of IP camera streams, with actual performance depending on camera settings, codecs, and the installed configuration.
Key Specifications
Specification
Details
Brand
GEUTEBRÜCK
Model
G-ST 8000+ G3/2U
Product type
CCTV recording and video management server
Form factor
2U, 19-inch rack mount
Processor
Intel Core i7, 12th Generation IoT
Memory
32 GB DDR5 ECC; optional upgrade to 64 GB
Operating system
Microsoft Windows Server 2022 Standard IoT LTSC
System storage
256 GB M.2 SSD; optional mirrored RAID 1 SSDs
Video storage
Up to 8 hot-swappable HDDs
Internal storage capacity
Up to 160 TB, depending on drive configuration
Recording performance
Up to 790 Mbit/s; 96 channels in the specified test configuration
Playback performance
Up to 430 Mbit/s; 46 channels in the specified test configuration
RAID support
RAID 0, 1, 5 and 6
Network interfaces
1 × 1 GbE and 2 × 1/2.5 GbE
Video outputs
4 × DisplayPort 1.4a
Power supply
2 × 500 W redundant, hot-swappable PSUs
Power consumption
Approximately 220 W in the documented test configuration
Dimensions (W × H × D)
482 × 89 × 710 mm
Operating temperature
0°C to +40°C
Warranty
3 years; optional 5-year coverage
