The Juniper EX4100-48P is a 48-port Gigabit Ethernet managed switch featuring PoE+ power delivery, high-speed uplinks, advanced network security, and centralized management. It is suitable for enterprise networks, IP surveillance systems, and commercial infrastructure.
The Juniper Networks EX4100-48P is a Layer 2 and Layer 3 enterprise access switch designed to provide secure, reliable, and high-performance network connectivity. It features 48 Gigabit Ethernet PoE+ ports supporting up to 30 W per port, four 1/10GbE SFP+ uplink ports, and four 10/25GbE SFP28 ports for stacking or additional uplink connectivity.
The switch supports Virtual Chassis technology, advanced network security, and centralized management through Juniper Mist Wired Assurance. Its rack-mountable 1U design, redundant power supply capability, and replaceable cooling fans make it suitable for demanding enterprise and CCTV network installations.
Key Specifications
Specification
Details
Brand
Juniper Networks
Model
EX4100-48P
Switch ports
48 × 1GbE RJ45
PoE standard
IEEE 802.3af/at (PoE+)
PoE power
Up to 30 W per port
PoE budget
740 W with one PSU; up to 1,440 W with two PSUs
Uplink ports
4 × 1/10GbE SFP+
Stacking ports
4 × 10/25GbE SFP28
Switching capacity
376 Gbps
Form factor
1U rack-mountable
Management
Juniper Mist Wired Assurance
Warranty
Confirm with supplier quotation
